Functional Outcome Following Hand and Wrist Level Replantation: A Retrospective Review

A B S T R A C T

Objective: Amputations of fingers and significant parts of upper limbs are common following industrial injuries. This study was aimed at assessing the functional outcome in patients with hand replantation following amputation at the level of distal forearm or wrist.
Methods: Patients presenting with amputation at the level of wrist and forearm between Jan 2015 and December 1018, with adequate follow up were included. The function in terms of total active motion at the fingers and wrist, sensory recovery, and patient satisfaction and DASH scores at the final follow up were noted.
Results: Four cases of replantation at the level of wrist and one replantation at distal forearm level were included in the study. A total of 3 patients were excluded for various reasons. The average follow-up period was 38 months. The average total active motion of fingers achieved was 212○. All patients recovered protective sensations.
Conclusion: Replantation of amputated major upper limb parts restores useful function and should be attempted. Minimizing ischaemia time, secure fixation, primary repair of structures and early motion are determinants of reasonable functional outcome. Level of evidence: IV.

Keywords

Amputation, replantation, major amputations, revascularization of hand, function after replantation, avulsion injuries, table saw injury

Introduction

Amputation of a significant part of the limb is a devastating injury that is likely to have long-lasting functional and psychological consequences on the patient's life. Replantation of body parts is undoubtedly one of the significant advances in managing these injuries that have been achieved in the latter part of the 19th century. Malt reported the first successful major replantation of a limb in 1962, soon followed by Chen in 1964 [1, 2]. Subsequently, with refinements in instrumentation and growing microsurgical experience, many more of such injuries have been salvaged [3-6].

While modern prosthetic devices are claimed to have improved performance, the prosthesis still is perceived as “merely a device supporting opposite healthy limb” [7]. A systematic review has suggested high satisfaction rates as well as the psychological superiority of replantation over the prosthesis [7-9]. In this retrospective study, we have tried to assess the functional outcome following replantation at the level of wrist and the forearm. This is first such report assessing function after replantation from Sultanate of Oman.

Methods

Permissions were obtained from the institutional ethical committee. The hospital medical records were searched between Jan 2015 and December 2018 for all patients getting admitted with amputation of significant parts of the upper extremity. The inclusion criteria were patients with amputation of major body parts undergoing replantation, with a minimum follow up of one year. The exclusion criteria were, patients with amputations distal to the wrist, i.e., through the palm and single or multi-digit amputations, minor amputations not needing admissions and patients not completing adequate follow-up.

Charts of the included patients were reviewed for the age, gender, extremity involved, the mechanism of injury, the ischaemia time, the procedure performed, outcome, complications if any and secondary surgeries performed. The total active motion (TAM) of the digits in the involved extremity and sensations over the digits and DASH scores at the final follow up were noted. These patients were contacted telephonically (visits could not be arranged due to COVID-19) to assess their current activity status, pain, and overall satisfaction, by an independent observer.

Case Description

Case 1

A 27-year-old male presented with amputation of his right hand with a paper cutting machine (Figure 1). He was brought to the hospital with the amputated part that could be attached and re-vascularised within three hours of his arrival. He recovered useful function, including some intrinsic muscle function (Figure 2). Primary repair of all structures helped him start early mobilization, and he needed minimum secondary interventions.

Figure 1: Amputation of the right hand at the level of the wrist, essential structures have been identified and tagged with sutures separately. Direct crushing of structures with hemostat should be avoided. The proximal part is being prepared.

Figure 2: The hand function after three years following replantation. The function of the long flexors as well as reasonably maintained thenar eminence suggesting intrinsic recovery can be appreciated.

Case 2

A 28-year-old male presented with crush amputation of his right forearm in a wood cutting saw. He sustained amputation through the distal forearm (Figure 3). The index and long fingers had a second level of injury. To save on ischaemia time, an external fixator was applied, and the hand was re-vascularized. The flexors to the index and long digits could not be repaired primarily due to multilevel nature. He needed multiple secondary surgeries including definitive skeletal fixation, tendon repair and CMC fusion. A good hand function could still be restored with timely and planned secondary interventions (Figure 4).

Figure 3: Patient with an amputation of his right forearm. The injuries over the index and long finger volar aspect can be appreciated. The hand was successful replanted.

Figure 4: Follow up a picture of the patient in figure 3 showing the recovery of useful function. However, as the primary repair of important tendons could not be achieved, he had to undergo multiple secondary procedures to reach this level of function.

Results

During this period, a total of 158 patients with amputations at various levels were admitted, while 118 body parts were replanted. 111 patients with distal level amputations were excluded. Among eight patients with amputation at the level of mid-palm and above, five patients were included. Two patients with inadequate follow up and one patient with significant avulsion that could not be replanted were further excluded. All these patients were male patients with an average age of 29 years. All included extremities were dominant right sides.

All five patients had an injury with a saw. Average ischaemia time from injury to reperfusion was 7 hours and included warm and cold ischaemia time. All the replanted parts survived without any immediate concerns. Two patients needed skin graft for wound closure. The average follow-up period was 38 months (30-48 months).

Multiple secondary surgeries performed were manipulation under anaesthesia (1), carpometacarpal joint (CMCJ) fusion (2), definitive skeletal fixation (1), tendon transfers (1), tenolysis (4), and delayed repair of tendons (2). Patient details have been summarized in (Table 1).

The average total active motion in fingers at the final follow up was 212°; the average 2PD was around 9 mm. All patients could use their hand for activities of daily living, and modified ADLS score was six while the average DASH score was 25.3 (Table 1). These patients expressed satisfaction about the procedure and had been back to meaningful employment while none of them had significant chronic pain. All were willing to undergo a similar procedure in future if such a need arises.

Table 1: Patient related information.

No.

Age/

Gender

Injury

Level

Side

Ischaemia time

Reperfusion

time

Average

TAM

Wrist F/E

Average

2PD

DASH

Score

Average Follow-up

Secondary procedures

Return to pre-injury occupation

1

28/M

Paper Cutting Machine

Wrist

Rt

1hr

3hr

220

20/30

9 mm

18.4

48 months

Skin grafting (Primary), MUA

Returned with change of work

2

25/M

Table saw

Wrist

Rt

6hr

3hr

230

25/35

11mm

24.2

42months

Skin grafting, tenolysis, CMC arthroplasty

Returned with change of work

3

38/M

Table saw

Wrist

Rt

4hr

4hr

190

35/45

9mm

26.7

41 months

Tenolysis

Changed Job

4

29/M

Table saw

Wrist

Rt

3.5hr

3hr

210

20/25

9mm

24.8

36 months

Tenolysis

Changed job

5

27/M

Table saw

Distal Forearm

Rt

7hr

3hr

200

45/45

10mm

32.4

34 months

Debridement, ORIF, Flexor tendon reconstruction, tendon transfer, Tenolysis, 1st web distraction, 1st CMC fusion

Returned with change of work



29.4

Averages





4.13 hr.

3.2 hr.

211.7



9.6 mm

25.3

38.5months





Abbreviations: DASH score: Disabilities of arm shoulder and hand score as filled by the patients at the last Follow up visit; MUA: Mobilization Under Anaesthesia; TAM: Total Active Motion; Hr.: Hours; mm: millimeters.


Discussion

Indications for replantation have evolved since replantation became a reality. Many severe and avulsion type of injuries, including amputation through critical areas (zone 2 amputation of a single digit) are now considered as relative contraindications due to their functional implications. Replantation of major parts is still favoured, considering the functional improvement they potentially provide. Thus, the functional outcome and not mere survival has become the primary determinant of success in replantation surgery [6, 7]. The functional restoration of major replants has multiple implications ranging from ischaemia time, surgery, and rehabilitation. Patient motivation can also influence the outcome.

Unlike digital replants, early transfer of these patients with major amputations to the microsurgical facilities is essential. The most critical determinant of survival and the muscle function is ischaemia time. Ischaemia time is especially crucial for more proximal level amputations with more substantial muscle mass involvement. Nevertheless, in this series, we noticed that the number of secondary procedures needed to restore useful function was proportional to the ischaemia time. The only patient reaching the hospital within an hour of injury recovered intrinsic muscle function. CMCJ arthrodesis, tendon transfers and claw corrections were needed in other patients due to loss of intrinsic muscle function.

The type of injury and amputation level also has implications on the possibility of replantation as well as the function. Among macro-replantations, the wrist and hand level are thought to have better outcome compared to more proximal amputations [10]. While we did not have a very proximal level amputation, the only wrist level amputation (bone level) in this series that could not be replanted had degloving of skin and soft tissues from the mid-arm levels, precluding its reattachment [11]. In avulsion type of injury as in the case above, getting suitable healthy vessel and the microcirculation within the skin is always tricky. Fortunately, all wrist level injuries were relatively sharp cuts with the saw, thus repairing structures was technically easier. One patient with forearm level amputation had minimal degloving as well as multilevel injury and needed secondary reconstruction of his tendons.

Adequate shortening of proximal and distal parts helps to prevent the need for additional soft tissue cover. The shortening should always be performed away from a critical joint. A procedure like proximal row carpectomy can help retain the functionally important wrist joint. At times when shortening is not possible, one should be prepared for emergency soft tissue cover, to preserve functionally important joints and protect the exposed vital structures.

Rigid skeletal fixation is pre-requisite for early mobilization. Care to avoid transfixing the joints, and the tendons can help improve the outcome. Fixation with k wires can be augmented by an external fixator to optimize the stability. With both flexor and extensor tendon repairs, all patients had an extension block splint with gentle flexion of the digits that additionally supported the fractures. Gentle early motion within the slab was started on day three following surgery and was continued for six weeks. It was followed by another four weeks of active mobilization without a splint. Muscle-strengthening was started after ten weeks. Four strands modified Kessler repair with 4’0 PDS was used for tendons. Early motion is critical in achieving a better functional outcome and should be encouraged [12].

The mean follow-up period was 38 months. Active motion that was 80% of the healthy opposite side could be achieved in these patients while the two-point discrimination was 8 to 10 mm. Multiple other authors have reported similar success rates [13, 14]. The DASH score indicated that patients could achieve reasonable functional independence. The activities most patients found difficulty doing required intrinsic muscle function, that was poor in all but the first patient.

Reports about secondary surgeries following replantation of major parts are also frequent [6, 15, 16]. Avoiding trans-fixation of the tendons and joints, early removal of hardware, and early motion can help reduce the number of secondary interventions [15, 17]. Timing of secondary interventions is also critical, any bone nonunion should be addressed early, while adequate time should be allowed for tissue equilibrium before undertaking tenolysis. Further interventions like CMC fusion, web deepening or claw correction should be decided when patient is using the hand and finds specific limitations. The available motors as well as scarred tissues and repaired neurovascular structures can pose difficulties in choice and execution of suitable options. In-spite of early motion, tenolysis was needed in 4 of the five patients. Secondary interventions were also needed to stabilize CMC joints (2) and claw correction (1) to address the loss of intrinsic muscle function. In the patient with forearm replantation, there was a second level injury. He had multiple secondary interventions. Primary repair of tendons could have helped us reduce a few of his secondary surgeries.

Functional analysis of a replanted extremity involves the assessment of the range of motion, stiffness, sensations, freedom from pain, and finally the appearance [16]. Various assessment scores objectively assess the hand functions based on ability and ease to perform day-to-day activities. DASH score is one such score that was used in this study [18].

Patients own subjective feeling about the replanted limb plays an essential role in meaningful vocational rehabilitation and can be a cause of the unfavourable outcome [19]. These patients need intensive physical therapy following replantation and possibly multiple secondary surgeries over the protracted phase of rehabilitation. They should be counselled about it before the surgery as well as in the post-operative period. All patients in our series, fortunately, were worksite injuries and were eager to get back to work as early as possible.

A few limitations of this study were its retrospective nature and inability to bring in the patients for final assessment due to COVID-19. Still, it provided us with meaningful insights about the overall results and functional implications of various factors.

Conclusion

Reduced ischaemia time, stable fixation, early motion, and timely secondary intervention are critical in achieving better functional results in replantation at the level of wrist and forearm.

Conflicts of Interest

None.

Funding

None.

Author Contributions

All the authors have contributed towards, planning and execution of the case and have helped in preparing this manuscript.
